All tabs. At least 3 items are required, and exactly 1 item must have isCenter: true.
currentIndex
int
Currently selected tab index.
onTap
ValueChanged<int>
Callback fired when a tab is tapped.
style
FloatingBottomNavigationStyle
Global layout and visual configuration for the bar.
FloatingBottomNavigationItem
Parameter
Type
Meaning
label
String
Text displayed below the icon or center avatar.
icon
IconData?
Default icon for a regular item.
activeIcon
IconData?
Icon shown when a regular item is selected.
iconSize
double?
Icon size for the regular state.
activeIconSize
double?
Icon size for the selected state.
iconBuilder
Widget Function(BuildContext, bool, Color)?
Custom icon builder for a regular item. Receives context, selected, and resolved icon color.
isCenter
bool
Marks the item as the single raised center item.
filledSelection
bool
When true, the selected regular item gets a filled circular background.
centerVariant
FloatingCenterButtonVariant
Center button appearance. Use iconOnly for a pure icon, or circleBackground for a circular background plus icon/content.
centerImage
ImageProvider<Object>?
Image source for the center item.
centerChild
Widget?
Custom center content when you do not use centerImage.
centerIcon
IconData?
Default icon for the center item.
activeCenterIcon
IconData?
Icon shown when the center item is selected.
centerIconSize
double?
Icon size for the center item in the regular state.
activeCenterIconSize
double?
Icon size for the center item in the selected state.
centerIconBuilder
Widget Function(BuildContext, bool, Color)?
Custom builder for the center icon content. Receives context, selected, and resolved icon color.
centerSize
double?
Center item size in the unselected state.
activeCenterSize
double?
Center item size in the selected state.
activeColor
Color?
Active icon or label color override for this item.
inactiveColor
Color?
Inactive icon or label color override for this item.
activeLabelStyle
TextStyle?
Active label style override for this item.
inactiveLabelStyle
TextStyle?
Inactive label style override for this item.
selectionGradient
Gradient?
Gradient used by the filled selected circle for a regular item.
FloatingBottomNavigationStyle
Parameter
Type
Meaning
outerPadding
EdgeInsets
Outer spacing around the whole navigation bar widget.
barHeight
double
Bar height on regular-width screens.
compactBarHeight
double
Bar height on narrow screens.
barTop
double
Top offset of the clipped bar background on regular-width screens.
compactBarTop
double
Top offset of the clipped bar background on narrow screens.
centerGap
double
Empty horizontal gap reserved for the center item on regular-width screens.
compactCenterGap
double
Empty horizontal gap reserved for the center item on narrow screens.
centerTop
double
Top offset of the raised center item. Smaller values move it upward.
adaptBottomSafeArea
bool
Adds bottom safe-area padding when enabled.
backgroundColor
Color
Fill color of the navigation bar background.
blurSigma
double
Blur strength applied by the background BackdropFilter.
backgroundShadow
BoxShadow?
Optional shadow for the clipped bar background.
curve
FloatingBottomNavigationCurve
Shape configuration for the raised top contour.
selectedItemColor
Color
Default selected color for regular items.
unselectedItemColor
Color
Default unselected color for regular items.
selectedCenterLabelColor
Color
Default selected label color for the center item.
unselectedCenterLabelColor
Color
Default unselected label color for the center item.
itemTopPadding
double
Top padding before regular item content starts.
itemSpacing
double
Vertical spacing between a regular item icon and label.
itemLabelStyle
TextStyle
Default label style for unselected regular items.
selectedItemLabelStyle
TextStyle
Default label style for selected regular items.
itemIconSize
double
Fallback icon size for regular items.
filledSelectionSize
double
Diameter of the filled selected background for regular items.
defaultSelectionGradient
Gradient
Default gradient used by filled regular items.
centerSelectedSize
double
Fallback center item size when selected.
centerUnselectedSize
double
Fallback center item size when unselected.
centerButtonPadding
EdgeInsets
Inner padding inside the circular center button.
centerButtonColor
Color
Background color behind the center image or child.
centerShadowColor
Color
Shadow color of the center button.
centerShadowBlur
double
Blur radius of the center button shadow.
centerShadowOffset
Offset
Offset of the center button shadow.
centerLabelSpacing
double
Fine-tunes the vertical distance between the center avatar and its label.
centerLabelStyle
TextStyle
Default label style for the unselected center item.
selectedCenterLabelStyle
TextStyle
Default label style for the selected center item.
centerForegroundGradient
Gradient
Foreground overlay gradient applied on top of the center image or child.
FloatingBottomNavigationCurve
Parameter
Type
Meaning
topY
double
Baseline Y position of the top edge on the left and right flat sections.
shoulderWidth
double
Width of the left and right transition zones leading into the center crest.
crestWidth
double
Diameter of the virtual circular guest used to build the convex top contour.
crestHeight
double
Vertical offset that lifts the circular guest above the bar top line.
topCornerRadius
double
Top-left and top-right corner radius of the bar background.
bottomCornerRadius
double
Bottom-left and bottom-right corner radius of the bar background.
slopeLift
double
Extra spacing between the bar top line and the circular guest. This slightly changes how open or tight the shoulder transition feels.
shoulderRoundness
double
Reserved parameter from an earlier curve model. It is currently kept for API compatibility and does not affect rendering.
crestRoundness
double
Reserved parameter from an earlier curve model. It is currently kept for API compatibility and does not affect rendering.
Tuning Tips
The current top contour is built with a convex-notch path, inspired by convex_bottom_bar, using a circular guest shape plus mirrored shoulder transitions.
Increase crestWidth to make the middle convex area wider and fuller.
Increase crestHeight to raise the center item further above the bar top edge.
Increase shoulderWidth to lengthen the shoulder transition on both sides.
Increase slopeLift slightly if the shoulder transition feels too tight around the center.
If the center avatar feels too low, reduce centerTop.
Layout Notes
Use outerPadding: EdgeInsets.zero to let the bar span the full page width.
adaptBottomSafeArea is enabled by default and keeps content above the iOS home indicator area.
